Description
Caractéristiques techniques
| Base form | rhomboidal | |
| Thickness of the insert S | 4.76 mm | |
| Insert version | neutral | |
| Length of cutting edge l | 12 mm | |
| Height of cutting edge | 4.76 mm | |
| Diameter of the cutting insert d | 12.7 mm | |
| Corner radius R | 1.2 mm | |
| Corner angle | 80 degrees | |
| Rake angle | 3 degrees | |
| Normal clearance angle (main cutting edge) | 0 degrees | |
| Normal clearance angle (flat cutting edge) | 0 degrees | |
| ISO-Code | CNMG 120412 | |
| Type of chip breaker | SG | |
| Tool material | Carbide | |
| Cutting media, manufacturers designation | HB7010-2 | |
| Coating | CVD | |
| Interface coding for insert | CNMG 120412 | |
| Insert designation | CNMG120412 | |
| Type of product | Cutter insert | |
| With ISO code | yes | |
| Number of teeth | 4 pcs. | |
| Direction of action | neutral | |
| Suitable for material | steel (P) | |
| Tolerance Class | M | |
| Finishing / roughing assignment | Roughing | |
| Type of fastening | Hole | |
| Chip breaker | yes | |
| Cutter version | rounded (E) | |
| Cutting conditions | continuous | |
| Weight | 10 g | |
| Content | 1 pcs. |
Identification et classification
| Référence article | 250324 HB7010-2 | |
| EAN / GTIN | 4069515016223 | |
| Réf. fabricant | 250324 HB7010-2 | |
| Fabricant/personne responsable | Hoffmann Supply Chain GmbH & Co. KG, Poststraße 15, 90471 Nürnberg, Deutschland, |
Tableau dapplication
